| Model No.: |
SG-3A4 （Metal Stand） |
| Main Specification |
| Mainframe Dimension |
Monitor: 396(W)*254(H)）mm; Base:206X230mm; Complete Machine:396W*206D*355H (Adjustable) |
| Power Supply |
External Power Supply Input: 200V-240V50/63Hz 2A, Output: 12V DC |
| Panel |
15.6″ Industrial grade panel |
| Touch screen |
True Flat Capacitive Touch |
| Resolution |
1366*768 |
| Mainframe Configuration |
| Main Board |
Android RK3288 |
Android A63 |
| CPU |
Quad-core 1.8GHz |
Quad-core 1.8GHz |
| Memory（RAM） |
2G |
2G |
| Hard Disk（ROM） |
8G/16G |
16G |
| Interface |
| USB |
6 USB ports（4 on board, 2 on the host side) |
| LAN |
1 LAN port |
| Wired |
LAN1*10/10OM |
| Wireless |
Wifi 2.4Gh BT4.0 |
| Audio (Optional) |
1 Audio input (MIC);1 Audio output |
| Option |
| Printer |
58mm thermal receipt printer |
| Camera |
5,000,000 pixel |
| Audio |
8W Loudspeaker |
| OS |
Android 7.1 |
| Operation Temperature |
0-40℃ |
