2D Wireless Barcode Scanner SX-102B5

•Wired, 2.4G wireless, Bluetooth, multi-mode free switching
•Multi-language (24 languages are supported by default and can be customized)
• Support offline storage of barcodes, a good helper for warehouse inventory
• Multi-system support (Windows, Android, Linux, MAC OS, IOS)
• Open distance: Bluetooth 10-20m, 2.4G wireless 100m
• Use more freely, one receiver can be connected to multiple scans

Send Inquiry
Categories: , , , Tag:
Description

Description



Model No.: SX-102B5
Physical Parameter
Material ABS+PVC+PC
Power Supply Charge 5V ±5% ；3.7V  2000mAH  lithium battery
Operating Current 400mA（working）；90mA（standby）；500mA（maximum）
Weight 146g±5g（Without cable）
Size L*W*H：196 * 87 * 70（unit:mm）
Color Black；Grayish white
Button Lifespan ＞100000times
Performance Parameter
Interface USB cable；Wireless 2.4G transmission
System Supported Linux，Android，Windows XP、7、8、10，MAC
Language Supported English; German; French; Spanish; Italian; Japanese
Sensor Planar CMOS sensor
Light Source Red LED(Aiming)+White LED(lighting)
Processor 32-bit ARM MCU
Storage 2M
Motion tolerance Code128： 15cm/sec;     QR： 25cm/sec
Resolution 4mil
Transmission Distance 100m
Bit Error Rate 1/5000000
Reading Mode Image
Trigger Mode Manual ；Continuous scanning;Auto-sensing
Prompt Mode Buzzer, Indicator Light（LED）
Print Contrast 25%
Charging time 8 hours
Working time 40 Hours
Decoding Capability 1D: ● Code25-Interleaved    ● Code25-Standard
● Code25-Matri          ● RSS-14
● Code39-Regular        ● Code39-FullASCII
● Code93-Regular        ● Code93-FullASCII
● Code128               ● Code11                ● UPCE0/E1
● EAN/GSL/UCC-128Auto   ● Codabar               ● MSI
● EAN/JAN-13            ● UPC-A                 ● JAN/EAN-8
● ChinaPost 25          ● Plessey
2D: ● Data Matrix    ● QR    ● PDF417       ●HanXin
● Micro PDF 417         ●Aztec
Scanning Distance 10mm-600mm
Scanning Angel Roll360°；Pitch65°；Yew65°
Scanning Depth Code39 5.83mil ： 6cm – 12cm
Code39 7.50mil ： 6cm – 12cm
Code128 5.83mil ： 5cm – 12cm
Code128 7.50mil ： 7cm – 13cm
Code QR 10.83mil ： 3cm – 11cm
Code QR 12.50mil （： 2cm – 20cm
Data Matrix 10.83mil ： 4cm – 11cm
Data Matrix 12.50mil ： 3cm – 13cm
Environment Parameter
IP Grade IP42
Operating Temp. 0 to 50℃ / 32 to 122℉
Storage Temp. 0 to 50℃ / 32 to 122℉
Operating Humidity 20% to 85%（No Condensation）
Storage Humidity 20% to 85%（No Condensation）
ESD Protection 15KV air discharge
Shock Resistance 1.2m free fall on concrete surface
