Description
| Model No.: | SX-112A3 |
| Physical Parameter | |
| Material | ABS+PC |
| Power Supply | DC 5V ±5% |
| Current | 0.09A(Standy), 0.20A(Working), 250mA(Max) |
| Power Consumption | 0.45W(Standy), 1.00W(Working), 1.25W(Max) |
| Weight | 230.0g±5g(Without Cable) |
| Size | L*W*H: 114.1 * 107.8 * 156.3mm |
| Color | Black / Grey |
| Performance Parameter | |
| Interface | USB |
| Systerm Supported | Linux，Android，Windows XP、7、8、10，MAC |
| Language Supported | English, France, German,Hungarian,Italy,Itali142,Japanese, Spanish,Finnish,Russian,Polish,Czech,Portuguese,Portuguese(Brazil),Greek,Swedish, Turkish F, Turkish Q(Support International Keyboard Language) |
| Sensor | Planar CMOS sensor 480 * 640 |
| Light Source | White Light LED Illuminate |
| Professor | 32-bit ARM MCU + DSP |
| Motion Tolerance | QR 10mil: 85cm/sec |
| Resolution | Code39 ≥5mil |
| Bit error rate | 1/5,000,000 |
| Reading Mode | Image |
| Trigger Mode | Auto-Sensing |
| Switch Button | Standby Mode |
| Prompt Mode | Buzzer + Indicate Light(LED) |
| Scanning Angel | Roll360°, Pitch45°,Yew60° |
| Print Contrast | ≥30% |
| Decoding Capability | 1D ■UPC-A ■JAN/EAN-8 ■JAN/EAN-13 ■Code 128 ■Code 39 ■Codabar ■Code 93 ■Interleaved 2 of 5 ■UPC-E ■UCC/EAN 128 ■GS1-128 ■ISBN-13 ■Industrial（Standard）2 of 5 ■Code 11 ■MSI Plessey ■Code32 ■GS1 Composite ■GS1 Databar ■Composite ■Matrix 2 of 5 |
| 2D ■PDF417 ■Micro QR Code ■QR Code ■Aztec code ■Data Matrix | |
| Depth of Field | QR Code 12.50mil(7 bit)：2cm – 15cm PDF417 9.17mil(7 bit)：3cm -15cm Data Matrix 12.50mil(8 bit)：2cm – 11cm Code 128 7.50mil(15 bit）：2cm – 12cm EAN13（10mil）：3cm – 12cm |
| Environment Parameter | |
| IP Grade | IP52 |
| Operating Temp. | 0 to 50℃ / 32 to 122℉ |
| Storage Temp. | 0 to 50℃ / 32 to 122℉ |
| Operating Humidity | 20% to 85%（No Condensation） |
| Storage Humidity | 20% to 85%（No Condensation） |
| ESD Protection | 15KV air discharge |
| Shock Resistance | 1.2m free fall on concrete surface |
| Environment Illumination | 0~100000LUX |
